Product Feature:
1. The transparent parts are optimized by the advanced illumination optics principle. The light is uniform, soft, glare-free and without ghosting, which effectively avoids the discomfort and fatigue of the construction workers.
2. Select advanced energy-saving lamp source, high luminous efficiency, long life of 50,000 hours; power factor greater than 0.8, high luminous efficiency, good light transmission.
3. Multi-channel anti-vibration structure and integrated design ensure long-term safe operation in high frequency and multi-frequency vibration environment.
4. It adopts high-strength alloy casing for special surface spraying and sealing treatment, and can be used for a long time under the harsh environment of high temperature and humidity and various corrosive.
Product Body Parameters :
Housing color available : milky frosted
| Model |
Number of buckles |
(L*W*H)(mm) |
(LF)(mm) |
Packing size(mm) |
(KG/PCS) |
Outer box gross weight |
| T218 |
6 |
600*120*86 |
260-300 |
680*290*310 |
1300g |
8.5kg |
| T236 |
10 |
1200*120*86 |
800-860 |
1280*290*310 |
2160g |
14.6kg |
| T258 |
12 |
1500*120*86 |
1080-1150 |
1580*290*310 |
2500g |
17kg |
Electrical Parameters:
Input: AC 100-277V
PF:>0.95
Driver Efficiency: >90%
THD: =<10% at full load
Optical Parameters:
Lumen Efficiency: 120 lm/w
Color Temperature: 3000K/4000K/5000K/6000K
CRI: >70 or > 80
Lifetime: 50,000 hrs
Certificate: CE-EMC, CE-LVD, ROHS
Warranty: 5 years
